CAN protocol 2.0 A/B (ISO 11898)
Rated voltage 12/24V
Switching input 8 x individually configurable, digital (H-/L-active)/analog
Switching output 4 x 5A (all PWM-capable, current measurement from 3A)
Standby current <25mA
Connection 10 x 6,3mm, 8 x 2,8mm
Mounting/installation on plug base or via fastening lug
Permissible ambient temperature -40°C up to 85°C
Material plastic
Protection class IP53
Product type CAN-Bus communication modules
